  • FRONT DRIVE SYSTEM Improved the operation more comfortable Easier to make the turning and Easier maintenance
  • The gearbox designed with synchro transmission makes very durable, as it is soft engaged which makes operating very smooth
  • 3-point rubber absorber under engine can anti-vibration greatly which makes operator comfortable operating feeling
Availability:


Product description

Lawn mower(Self-propelled)

Engine

China engine

Engine type

Gasoline,4-stroke

Engine displacement

173 cc

Engine power

3.0 kW at 3000 RPM

Tank capacity

1.0 Liter

Air filter

Dual element (paper and foam)

Starter

Recoil

Emission

EU 5

Cutting width

60 cm

Cutting height

25-75 mm

Walking type

Self-propelled

Trimming speed

3000 RPM

Walking speed

3.6 km/h

Operation Handle

fixed

Transport way

wheel

Wheel size

8”

Carton size

80 x 57 x 43 cm

Loading qty - 40HC without pallets

347 pcs

advantage

1

FRONT DRIVE SYSTEM

Improved the operation more comfortable_x005f

• Easier to make the turning

• Easier maintenance



2

With the mulching guard

fitted in the lawn mower, the grass is cut into very tiny pieces, which disappear between the blades of

grass and rot down to provide nat-

ural fertiliser for the grass.


3

The deck is formed by one piece 2.5 mm thickness stee makes the machine  strong  and stable

4

Water inlet can let the deck easy to be cleaned

5.1
5.2

the  gearbox designed with synchro  tranmssition  makes  very durable,  as it is  soft engaged which  makes operating very smooth

6

3-point rubber absorber under engine can anti-vibration greatly which makes operator comfortable operating feeling


7

mud scraper on all wheels design makes walking keep smooth

8.18.2

Optional  wheel cover make your lawn mower  unique


1

1. Product procession

Product procession

5

Product in QC





Production

1


PQC

Testing

Final product


2

1. wrapped packing 2 warehousing 4


3









17
